Model	CHN-DP-V09003
Power	24W
Flow	9 L/h
Pressure	3.5 Bar
Stroke	120 N/m
Wet Suction Range	1.5m
Dosing Pump Tubing	4 x 6mm
Interface	DN 15mm
Power Supply	220V
Repeated Measurement Accuracy	-5%~5%
Allowable Ambient Temperature	5℃~180℃ (PTFE pump head ),
Allowable Medium Viscosity	High viscosity pump head ≤ 1000 mPA.s
Particle Diameter	≤0.15mm
Protection Class	IP55
Insulation Class	F
Weight	2.9 kg
Warranty Period	12 Months
