Model		CHN-U12
Voltage		24V DC, 36V DC, 48V DC, 120V AC, 230V AC (Optional)
Max. Load		5000N
No-Load Speed		4.5mm/s
Full-Load Speed		4mm/s
Rated Speed		5000RPM
Stroke		50/ 100/ 150/ 200/ 250/ 300/ 350/ 400/ 450mm (Optional, 50-1200mm can be customized)
Duty Cycle		10%
IP Grade		IP65
Ambient Temperature		-40℃ ~ +65℃
Installation		Bracket mounting, the installation size can be adjusted flexibly.
Potentiometer		1K
Noise		<60db
Length of Cable		1.2m
Weight		11kg
Applications		Ventilation system for agricultural livestock breeding
